Corrugated Tubular 5000W Power Wirewound Resistor fixed Breaking

Corrugated Tubular 5000W Power Wirewound Resistor Fixed Breaking

Corrugated Tubular Wirewound Brake Resistors

Rated power:15W-20KW

1. Multi-terminal and multi-resistance ,fixed, adjustable are available,out wire's length are available following

customer requirement; Special terminals are available for unusual applications.
2. Element consisting of a wave-shaped alloy ribbon or non-wave shaped alloy wire.
3. Good dissipation ,high stability, high power rating,high over load and long life.
4. Conforms to the ROHS standard and the LEAD-FREE non-lead standard.

Performance Charactertics
Test	Conditions of Test	Testing Results
Resistance Tolerance	Testing Voltage ≤3V,Ambient Temperature 25℃	B---D---F---G---J--K
Rated Load	40℃,rated voltage,1hour	△R≤±(3％+0.1Ω)
Short Time Overload	5 times rated power for 10s	△R≤±(0.2％+0.1Ω)
Dielectric Withstand Voltage	2 times Rated Power Voltage +1kv AC 60s (with grounding), leakage current 2.5mA ; 2 times Rated Power Voltage +2kv AC 60s (with grounding), leakage current 2.5mA ;	△R≤±(0.1％+0.05Ω)
Insulation Resistance	500V DC	≥10GΩ1Min
Terminal Tensile Strength	40N	No off
Vibration resistance	1.5mm,10-55-10Hz,each 2hours	No damage,No off
Load Life	at rated voltage,90 min "On",30 min "Off" ,total 500hours	△R≤±(3％+0.1Ω)
Low Temperature Resistance Testing	store at -65℃±3℃ for 2H	△R≤±(1%+0.1Ω)
High Temperature Resistance Testing	store at 70 ℃± 2 ℃ for 16h, connect the rated voltage DC circuit for 1s	△R≤±(1%+0.1Ω)
Non-flammability	10 times rated power, power on for 5s	without combustion

Corrugated Tubular 5000W Power Wirewound Resistor fixed Breaking

1.Main Products

2.Factory photos :

Corrugated Tubular 5000W Power Wirewound Resistor fixed Breaking
